Motor Pairing Considerations

Most customers speak to us before purchasing to ensure compatibility with:

  • Load profile: Is the motor driving a constant load, variable load, or shock loads?
  • Duty cycle: Continuous vs intermittent use, peak vs average power demand.
  • Environment: Marine (corrosion, humidity), agriculture (dust, mud), motorsport (heat, vibration).
  • Power/torque curve (does the motor deliver the torque at the speed you need?).
  • Cooling requirements (air vs liquid cooled, ventilation needs).

Contact us for any questions on motor pairing!

The ME0708 is a high-efficiency brushed permanent magnet DC motor designed for battery-powered applications. It delivers up to 4.8 kW of continuous power and can produce 15 kW for short-duration operation of up to one minute. The motor operates with input voltages ranging from 12 to 48 VDC and is rated for 100 amps continuous current, with a peak capability of 300 amps for one minute. The motor weighs approximately 28 lbs (12.7 kg).

Key Features

1) Armature Resistance Line to Line is 0.010 Ohms.
2) The number of brushes is 8.
3) The maximum recommended rotor speed is 5000 rpm.
4) Voltages from 0 to 48 VDC input.
5) Torque constant of 0.13 Nm per Amp
6) The Inductance Phase to Phase is 0.06 Milli-Henry.
7) Armature Inertia is 180 Kg Cm Squared.
8) Continuous current of 100 Amps DC.
9) Peak current of 300 Amps DC for 1 minute.
10) Weight of 28 pounds.
11) Peak Stall Torque if 38 Nm.
12) This is an Open Frame, Fan Cooled motor.

Specifications

Product Datasheet

 -

Dimensions

 -

Manual

 -

Manufacturer Part Number

 ME0708 (selected)
