The Motenergy ME1118 is a compact, high-performance permanent magnet synchronous motor designed for demanding electric vehicle and industrial applications. Featuring a brushless, 3-phase Y-connected architecture with an axial air gap, it offers maintenance-free operation, up to 90% efficiency, and a continuous current rating of 80 amps across a 17-67 VAC operating range. Its robust design ensures reliable, long-lasting performance in a wide range of applications.
1) This is a 8 pole motor (4 pole pairs).
2) The Phase to Phase winding resistance is 0.0095 Ohms.
3) The maximum recommended rotor speed is 5000 RPM.
4) Voltages from 0 to 96 VDC input to the control.
5) Torque constant of 0.19 Nm per Amp
6) The Inductance Phase to Phase is 0.12 Milli-Henry.
7) Armature Inertia is 52 Kg Cm Squared.
8) Continuous current of 80 Amps AC.
9) Peak current of 220 Amps AC for 1 minute.
10) Weight of 23 pounds.
11) Peak Stall Torque if 60 Nm.
12) This is an Open Frame, Fan Cooled motor.
13) Has internal temperature sensor.
