Motenergy ME1716 Motor

Motenergy ME1716 Motor

Out of stock
£550.00
£550.00

Excluding VAT

Ask for lead time / quote

Motor Pairing Considerations

Most customers speak to us before purchasing to ensure compatibility with:

  • Load profile: Is the motor driving a constant load, variable load, or shock loads?
  • Duty cycle: Continuous vs intermittent use, peak vs average power demand.
  • Environment: Marine (corrosion, humidity), agriculture (dust, mud), motorsport (heat, vibration).
  • Power/torque curve (does the motor deliver the torque at the speed you need?).
  • Cooling requirements (air vs liquid cooled, ventilation needs).

Contact us for any questions on motor pairing!

The Motenergy ME1716 motor
A brushless 3-phase, Y-connected Permanent Magnet Synchronous Motor, otherwise known as PMSM motor. Its brushless design requires no maintenance.


Commutation is achieved by an internal Sine/Cosine speed sensor, an input voltage of 24-72 VDC, 100 amps continuous, up to 300 amps for 30 seconds.

1) Designed for 24 - 96 VDC battery operated equipment
2) Set for 100 amps continuous
3) Maximum rotor speed 5500rpm
4) Torque: 9.5Nm
5) Internal temperature sensor equivalent to the KTY84-130
6) Internal Sine/cosine position sensor
7) Weight: 20.5 pounds


These patented radial flux motors are designed to work with sinusoidal (sine wave) controllers such as the Sevcon Gen4.



NOTE: We do not recommend the use of square wave controllers with these motors. This may reduce the durability and efficiency of the motor, as well as void the warranty.

Specifications

Product Datasheet

 -

Dimensions

 -

Manual

 -
