Motenergy ME1717 Motor

Motenergy ME1717 Motor

2 in stock
£550.00
£550.00

Excluding VAT

Motor Pairing Considerations

Most customers speak to us before purchasing to ensure compatibility with:

  • Load profile: Is the motor driving a constant load, variable load, or shock loads?
  • Duty cycle: Continuous vs intermittent use, peak vs average power demand.
  • Environment: Marine (corrosion, humidity), agriculture (dust, mud), motorsport (heat, vibration).
  • Power/torque curve (does the motor deliver the torque at the speed you need?).
  • Cooling requirements (air vs liquid cooled, ventilation needs).

Contact us for any questions on motor pairing!

Featuring a 3-phase, Y-connected PMSM design, the Motenergy ME717 achieves efficiencies of up to 92% across a battery voltage range of 24-60 VDC. The motor is rated for continuous operation at 100 A when supplied with 48 VDC.

Key Features


 1) Inductance (at 1000 Hz): 39 to 43.5 µH
 2) Maximum Mechanical Rotor Speed: 6,000 rpm
 3) Winding Resistance (Phase-to-Phase): 4.9 mΩ
 4) Sensor Type: Hall sensor with +5 VDC supply
 5) Weight: 11 kg
 6) Number of Poles: 10 poles (5 pole pairs)
 7) Protection Rating: IP65-rated casing
 8) Maximum Current: 300 A for up to 2 minutes
 9) Continuous Current: 100 A
 10) Temperature Sensor: KTY84-130 winding temperature sensor
 11) Magnet Specification: N38UH, rated to 180°C
 12) Front Bearing: NSK 6206
 13) Rear Bearing: NSK 6203
 14) Rotor Inertia: 0.00224 kg·m²



Specifications

Product Datasheet

 -

Dimensions

 -

Manual

 -

Manufacturer Part Number

 ME1717 (selected)
