Motenergy ME2009 Motor

Motenergy ME2009 Motor

Out of stock
£620.00
£620.00

Excluding VAT

Ask for lead time / quote

Motor Pairing Considerations

Most customers speak to us before purchasing to ensure compatibility with:

  • Load profile: Is the motor driving a constant load, variable load, or shock loads?
  • Duty cycle: Continuous vs intermittent use, peak vs average power demand.
  • Environment: Marine (corrosion, humidity), agriculture (dust, mud), motorsport (heat, vibration).
  • Power/torque curve (does the motor deliver the torque at the speed you need?).
  • Cooling requirements (air vs liquid cooled, ventilation needs).

Contact us for any questions on motor pairing!

Motenergy ME2009 48 V PMSM Traction Motor

The ME2009 is a 3‑phase Permanent Magnet Synchronous Motor (PMSM) designed for 24-60 V systems, with high efficiency and a rugged IP65‑rated enclosure. We recommend to use in light EVs, industrial drives, and small traction applications.

Key Specs

  • 92% efficiency at 24–60 V

  • Continuous current: 150 A @ 48 V

  • Peak current: 450 A for 2 minutes

  • Maximum mechanical speed: 6000 rpm

  • Winding resistance: 2.5 mΩ phase‑to‑phase

  • Inductance: 19 µH @ 1 kHz phase‑to‑phase

  • Poles: 10 (5 pole pairs)

  • Sensor: Hall sensors, +12 V

  • Temperature sensor: KTY84‑130

  • Magnet grade: N38UH (180 °C)

  • Ingress protection: IP65

  • Weight: 12.8 kg

ME2009 Physical Dimensions

  • Overall length: ~ 260–280 mm

  • Body diameter: ~ 180 mm

  • Shaft diameter: 22.2 mm (7/8")

  • Shaft length: ~ 50 mm

  • Bolt circle (143T): 5.875" (149 mm)

  • Pilot diameter: 4.5" (114 mm)

Motenergy ME2009

Feature Value
Voltage 24–60 V
Continuous Current 150 A
Peak Current 450 A
Max Speed 6000 rpm
Efficiency 92%
Weight 12.8 kg
Shaft 7/8"
Mount NEMA 143T / 56C
Dimensions ~260–280 mm L × 180 mm D

Specifications

Product Datasheet

 -

Dimensions

 -

Manual

 -
